75ton Large Mining Machine Crawler Excavator Sy750h

Get the powerful 75ton Large Mining Machine Crawler Excavator Sy750h from our factory. Perfect for heavy-duty mining operations. Contact us today.
Request a Quote


Basic Info.

Model NO.
CE, ISO9001: 2000
Max.Digging Height
Max. Digging Reach
Operating Weight
Engine Power
Rated Speed
5.4 Km/H
Max. Digging Depth
7605 mm
Transport Package
Comply with Export Packaging Requirements
China, Hunan
Production Capacity
100 Units Per Month

Product Description

Our company will offer you the high quality products with a low price, quick delivery,and professional after-sale service.

Excellent performance

10% higher work efficiency with 10% lower consumption, huge digging force, specially designed for mining working condition.more smooth operation.

Super adaptation

More than 20 kinds of optional working deivices, good protection of the engine with multiple filtration system, independent oil radiator to keep proper working temperature.

Longer lifetime

By comprehensive testing system, the designed lifetime reaches 25000 hours, 15% less pressure of key compents compared with 40 tonage models, but 30% longer lifetime.

Low maitenance cost

Much more convenient maintenance operation, durable oil and filters to make longer maitenance period, 50% less expense.

Engine Rated power 377/1800 kW/rpm
Operation Range Operating weight 89900 kg
Max. digging height 11062mm
Max. digging depth 7605mm
Max. dumping height 7235mm
Max. vertical digging depth 4313mm
Max. digging reach 12037mm
Min. swing radius 5520
Height at min.swing radius 9780
Dimensions Transport length 12865mm
Transport width 4030mm
Transport height 4855mm
Upper width 3460mm
Tail swing radius 4220mm
Min. ground clearance 880mm
Undercarriage/Working Device Std. track shoe width 600 mm
Bucket capacity 4.2 m³
Track length 5865mm
Performance Travel speed 4.5/2.9 km/h
Swing speed 7.3rpm
Gradeability 70%35°
Ground pressure 131kPa
Bucket digging force 672kN
Arm digging force 792kN

75ton Large Mining Machine Crawler Excavator Sy750h
75ton Large Mining Machine Crawler Excavator Sy750h
75ton Large Mining Machine Crawler Excavator Sy750h
75ton Large Mining Machine Crawler Excavator Sy750h

About Our Company
We are a professional trading firm, specializing in providing international markets with a variety of top Chinese construction machinery.  We are the authorized dealer of  . We have an annual sales volume of 50 million USD bussiness, containing 600-700 units construction machines. With a rich experience of  many years, we have acquired the requisites expertise and excellence in our ddomain. Having scaled phenomental heights of success, today we stand tall amidst a number of competitors across the world. A well coordinated and expertly managed operation system and professional international sales team enable us to turn orders into final products and export them to approximately 60 countries and several regions across the globe.
75ton Large Mining Machine Crawler Excavator Sy750h
75ton Large Mining Machine Crawler Excavator Sy750h

1: What kind terms of payment can be accepted?
A: For terms of payment, L/C, T/T, D/A, D/P, Western Union (can be) could accepted
2: What certificates are available in Machinery?
A: For the certificate, we have CE, ISO, Gost, EPA(USA)CCC,
3: What about the delivery time?
A: 30 days after receiving the deposit.
4: What about the warranty time?
A: 12 months after shipment or 2000 working hours, whichever occuts first.
5. What about the Minimum Order Quantity?
A: The MOQ is 1 pcs
