Basic Info.
Model NO.
JC45G
Type
Small Loader
Transport Package
International Package
Trademark
RUMLIFT
Origin
China
HS Code
8429510000
Production Capacity
3000/Year
Product Description
Advantage :
1engine : Chinese Changchai and Japan YANMAR , Mitsubishi engine, Italy EPA4 Kohler option
2.Italian BP hydraulic pump
3.American White motor
4.hydraulic self-leveling system
5.bobcat type quick coupler
FAQ:
Q1: How long is the Warranty for RUM LIFT product?
A1: RUMLIFT provides 24 months or 2500 hours for the whole machine from on board time.
Q2: How about the delivery time?
A2: Usually RUMLIFT producing time is 15- 20 days after we receive the advanced payment. For some standard products, we may have stock and could delivery immediately.
Q3: How about the continuous working time for the electric series forklifts & Stackers ? And How long time to charge the battery full ?
A3: RUMLIFT battery continuous working time is around 4-6hours( depend on battery volume and people operation ), when the red light of dashboard flashing ,need to charging ,about 5 hours can be finish ,RUMLIFT'S charge is intelligent,once the battery is full , will stop to charging .
Q4 How about the battery working life ?
A4: our Battery is from DIN standard battery ( Germany technology), can be working 6 years without any problem.
Q 5 : Can RUM LIFT provide customized products? OEM products or ODM products?
A5: Yes, RUMLIFT can provide customized products per your request, both OEM and ODM are acceptable. We do a lots of non-standard products, welcome your special request.
Q 6 : What's the specification of the chargers?
A6: Our chargers voltage could be 110V 220V 240 380V 415V ( 1 phase or 3 phases,50/60HZ). Power plug could be USA/UK/AUSTRALIA/EUPROPEAN standard.
Q 7 : Could we request our own color for the products?
A7: Yes, of course,We have orange red ,red ,white ,green, blue and so on , you just need to offer us the RAL code.
Looking for ideal Different Color Side Forklift Manufacturer & supplier ? We have a wide selection at great prices to help you get creative. All the Electric Side Forklift are quality guaranteed. We are China Origin Factory of Side Forklift In Yellow. If you have any question, please feel free to contact us.
1engine : Chinese Changchai and Japan YANMAR , Mitsubishi engine, Italy EPA4 Kohler option
2.Italian BP hydraulic pump
3.American White motor
4.hydraulic self-leveling system
5.bobcat type quick coupler
| Model | JC35 | JC45G | JC60G | JC65G | JC70 | JC100 |
| Rated Operating Capacity | 500 | 700 | 850 | 900 | 1000 | 1200 |
| Tipping load(Kg) | 1000 | 1400 | 1700 | 1800 | 2000 | 2400 |
| Bucket Capacity(m3) | 0.25 | 0.4 | 0.5 | 0.5 | 0.5 | 0.4-0.5 |
| Lifting force(kg) | 1000 | 1950 | 1950 | 2410 | 2700 | 2200 |
| Hydraulic Pump Flow(L/min) | 40 | 75 | 75 | 75 | 100 | 75/125 |
| Engine power(HP) | 35 | 50 | 60 | 65 | 80 | 100 |
| Weight(Kg) | 2200 | 2750 | 3240 | 3300 | 3600 | 3800 |
| Max. Travel Speed(km/h) | 8 | 12 | 12 | 10 | 12 | 12/18 |
| Grade ability (° ) | 20 | 20 | 20 | 20 | 20 | 20 |
| Tire | 8.5- 15 | 10- 16.5 | 12-16.5 | 12- 16.5 | 12- 16.5 | 12-16.5 |
| Fuel hyd. Oil capacity(L) | 50/50 | 60/60 | 80/80 | 80/80 | 70/70 | 80/80 |
| A. Height at Maximum Extension | 3300 | 3670 | 4000 | 3690 | 3690 | 3780 |
| B. Hinge Pin Height mm | 2725 | 2900 | 3100 | 2920 | 2920 | 3150 |
| C. Total Height mm | 2000 | 2050 | 2160 | 2160 | 2160 | 2040 |
| D. Length with Bucket mm | 2950 | 3420 | 3490 | 3540 | 3540 | 3450 |
| E. Length without Bucket mm | 2300 | 2640 | 2750 | 2780 | 2780 | 2540 |
| F. Width with Bucket mm | 1400 | 1740 | 1880 | 1880 | 1880 | 1900 |
| G. Track Width mm | 1080 | 1450 | 1500 | 1500 | 1500 | 1560 |
| H. Wheelbase mm | 891 | 991 | 991 | 1091 | 1020 | 1020 |
| J. Ground Clearance mm | 140 | 185 | 205 | 205 | 200 | 260 |
| K. Dumping Angle | 40° | 40° | 40° | 40 | 40 | 45 |
| L. Dumping Height mm | 2050 | 2310 | 2400 | 2330 | 2330 | 2400 |
| M. Maximum Reach mm | 790 | 710 | 750 | 710 | 700 | 700 |
