Basic Info.
Model NO.
hx35
Usage
Special Excavator, Marine Excavator, Mining Excavator, GM Excavator, Garden, Farmland, Road Construction
Bucket
Backhoe
Transmission
Hydraulic Transmission
Drive Type
Internal Combustion Drive
Bucket Capacity
0.1cbm
Size
Small-Scale
Certification
CE, ISO9001: 2000, EPA; Euro5
Condition
New
Engine
Laidong/ Yanmar/Kubota/Changchai
Climbing Gradient
30 Degree
Multifunction
Auger, Hammer, Rake, Ripper, Gripper
Product Usage
Digging Machine
Attachments
Grapple; Breaking Hammer; Angle
Color
Customized
MOQ
1 Set
Crawler Type
Standard or Telescopic Chassis
Crawler Material
Rubber or Steel
Function
Agriculture, Construction, Garden
Engine Type
4 Cylinder
Optional Machine Weight
0.8 to 6 Tons
Closed Cabin
Optional
Transport Package
Container/Wooden Box
Specification
HX35
Trademark
Hixen
Origin
China
HS Code
8429521200
Production Capacity
1000 Set/Year
Packaging & Delivery
Package Size
428.00cm * 150.00cm * 220.00cm
Package Gross Weight
3500.000kg
Product Description
![3.5 Ton Yanmar Kubota Yanmar Engine Swing Boom Telescopic Crawler Open Closed Cabin with Air Conditioner AC Steel Track for Mini Excavator Clamshell Shovel](http://img6.grofrom.com/www.bailemachineco.com/226f3j00lifVuVWMsrph/3-5-Ton-Yanmar-Kubota-Yanmar-Engine-Swing-Boom-Telescopic-Crawler-Open-Closed-Cabin-with-Air-Conditioner-AC-Steel-Track-for-Mini-Excavator-Clamshell-Shovel.webp)
Who We Are:
Shandong HIXEN Machinery Co., Ltd is one of China leading manufacturers of mini excavators. The products has got CE approved, satisfying Euro5 and EPA Tier4 emission standard and have been supplied to over 30 countries with great reputation.
What We Offer:
1. Products of Mini Excavators from HX08 to HX35, Kubota engine are optional.
2. Pre-sale, middle-sale and after-sale all-around service.
3. Training of machine operation, daily maintenance with instruction manuals.
4. 7*24 Technical support for any trouble shooting with our machines.
5. OEM/ODM service for excavator wholesalers/trading companies/distributors/local agents.
![3.5 Ton Yanmar Kubota Yanmar Engine Swing Boom Telescopic Crawler Open Closed Cabin with Air Conditioner AC Steel Track for Mini Excavator Clamshell Shovel](http://img6.grofrom.com/www.bailemachineco.com/226f3j00lhfVgvWIvrpi/3-5-Ton-Yanmar-Kubota-Yanmar-Engine-Swing-Boom-Telescopic-Crawler-Open-Closed-Cabin-with-Air-Conditioner-AC-Steel-Track-for-Mini-Excavator-Clamshell-Shovel.webp)
![3.5 Ton Yanmar Kubota Yanmar Engine Swing Boom Telescopic Crawler Open Closed Cabin with Air Conditioner AC Steel Track for Mini Excavator Clamshell Shovel](http://img6.grofrom.com/www.bailemachineco.com/226f3j00VlUWgnhoapri/3-5-Ton-Yanmar-Kubota-Yanmar-Engine-Swing-Boom-Telescopic-Crawler-Open-Closed-Cabin-with-Air-Conditioner-AC-Steel-Track-for-Mini-Excavator-Clamshell-Shovel.webp)
Product Features
1. The mini excavator is equipped with top brand engine such as Yanmar or Kubota, satisfying the EURO5 and EPA Tier4 emission standard.
2. The hydraulic system adopts the load-sensitive mechanism, making each move operated smoothly with help of the branded pump.
3. With many years' manufacturing experience, the engines and hydraulic systems are matched perfectly, so the mini excavator has enjoyed the best efficiency and performance.
4. The whole body adopts the reinforced material, making it stronger from the initial.
5. The scientifically compact design of each model, increasing its reliability while decreasing the possibilities of machine breakdown.
6. Most models are standard with hydraulic control and boom swing functions. So the mini excavators could make more moves easily at the lowest time. Also, it releases hard work of the operators.
7. With retractable undercarriage or chassis, the mini excavator could pass through the narrow space easily. Together with double speed motor, it can walk faster improving all work efficiency.
8. Standard with one backup hydraulic oil pump, so that many tools such as Hammer, Auger, Rake, Thumb, Grapple etc. could be attached to complete various jobs.
![3.5 Ton Yanmar Kubota Yanmar Engine Swing Boom Telescopic Crawler Open Closed Cabin with Air Conditioner AC Steel Track for Mini Excavator Clamshell Shovel](http://img6.grofrom.com/www.bailemachineco.com/226f3j00cWRVgahrTpzl/3-5-Ton-Yanmar-Kubota-Yanmar-Engine-Swing-Boom-Telescopic-Crawler-Open-Closed-Cabin-with-Air-Conditioner-AC-Steel-Track-for-Mini-Excavator-Clamshell-Shovel.webp)
![3.5 Ton Yanmar Kubota Yanmar Engine Swing Boom Telescopic Crawler Open Closed Cabin with Air Conditioner AC Steel Track for Mini Excavator Clamshell Shovel](http://img6.grofrom.com/www.bailemachineco.com/226f3j00blGVzpWssguh/3-5-Ton-Yanmar-Kubota-Yanmar-Engine-Swing-Boom-Telescopic-Crawler-Open-Closed-Cabin-with-Air-Conditioner-AC-Steel-Track-for-Mini-Excavator-Clamshell-Shovel.webp)
![3.5 Ton Yanmar Kubota Yanmar Engine Swing Boom Telescopic Crawler Open Closed Cabin with Air Conditioner AC Steel Track for Mini Excavator Clamshell Shovel](http://img6.grofrom.com/www.bailemachineco.com/226f3j00qlYVzViWvrph/3-5-Ton-Yanmar-Kubota-Yanmar-Engine-Swing-Boom-Telescopic-Crawler-Open-Closed-Cabin-with-Air-Conditioner-AC-Steel-Track-for-Mini-Excavator-Clamshell-Shovel.webp)
![3.5 Ton Yanmar Kubota Yanmar Engine Swing Boom Telescopic Crawler Open Closed Cabin with Air Conditioner AC Steel Track for Mini Excavator Clamshell Shovel](http://img6.grofrom.com/www.bailemachineco.com/226f3j00ohYVzvlMapuW/3-5-Ton-Yanmar-Kubota-Yanmar-Engine-Swing-Boom-Telescopic-Crawler-Open-Closed-Cabin-with-Air-Conditioner-AC-Steel-Track-for-Mini-Excavator-Clamshell-Shovel.webp)
Engine : Koop,Changchai,Laidong,Xinhai,Yanmar,Kubato,Perkins
Control: Hydraulic pilot or mechanical
Cabin: Open cabin or canopy and close cabin
Track: Rubber and steel track/crawler are optional
Air Conditioner: Air conditioning system could be equipped within the enclode cabin.
Chassis: The retractable track or chassis could be choosed.
Motor: High-low two speed motor is optional
Color: Yellow,Orange,Red,Blue,Green,Black.Etc
![3.5 Ton Yanmar Kubota Yanmar Engine Swing Boom Telescopic Crawler Open Closed Cabin with Air Conditioner AC Steel Track for Mini Excavator Clamshell Shovel](http://img6.grofrom.com/www.bailemachineco.com/226f3j00ohfVuFiIJzgl/3-5-Ton-Yanmar-Kubota-Yanmar-Engine-Swing-Boom-Telescopic-Crawler-Open-Closed-Cabin-with-Air-Conditioner-AC-Steel-Track-for-Mini-Excavator-Clamshell-Shovel.webp)
![3.5 Ton Yanmar Kubota Yanmar Engine Swing Boom Telescopic Crawler Open Closed Cabin with Air Conditioner AC Steel Track for Mini Excavator Clamshell Shovel](http://img6.grofrom.com/www.bailemachineco.com/226f3j00BWRVgahtmpul/3-5-Ton-Yanmar-Kubota-Yanmar-Engine-Swing-Boom-Telescopic-Crawler-Open-Closed-Cabin-with-Air-Conditioner-AC-Steel-Track-for-Mini-Excavator-Clamshell-Shovel.webp)
![3.5 Ton Yanmar Kubota Yanmar Engine Swing Boom Telescopic Crawler Open Closed Cabin with Air Conditioner AC Steel Track for Mini Excavator Clamshell Shovel](http://img6.grofrom.com/www.bailemachineco.com/226f3j00eWUiughsOrzl/3-5-Ton-Yanmar-Kubota-Yanmar-Engine-Swing-Boom-Telescopic-Crawler-Open-Closed-Cabin-with-Air-Conditioner-AC-Steel-Track-for-Mini-Excavator-Clamshell-Shovel.webp)
![3.5 Ton Yanmar Kubota Yanmar Engine Swing Boom Telescopic Crawler Open Closed Cabin with Air Conditioner AC Steel Track for Mini Excavator Clamshell Shovel](http://img6.grofrom.com/www.bailemachineco.com/226f3j00BVUirhWCJgzl/3-5-Ton-Yanmar-Kubota-Yanmar-Engine-Swing-Boom-Telescopic-Crawler-Open-Closed-Cabin-with-Air-Conditioner-AC-Steel-Track-for-Mini-Excavator-Clamshell-Shovel.webp)
![3.5 Ton Yanmar Kubota Yanmar Engine Swing Boom Telescopic Crawler Open Closed Cabin with Air Conditioner AC Steel Track for Mini Excavator Clamshell Shovel](http://img6.grofrom.com/www.bailemachineco.com/226f3j00eVGhpviJhurW/3-5-Ton-Yanmar-Kubota-Yanmar-Engine-Swing-Boom-Telescopic-Crawler-Open-Closed-Cabin-with-Air-Conditioner-AC-Steel-Track-for-Mini-Excavator-Clamshell-Shovel.webp)
Here we list some basic product parameters, kindly please check and select the one which suits your jobs. For more information, you can contact us immediately.
![3.5 Ton Yanmar Kubota Yanmar Engine Swing Boom Telescopic Crawler Open Closed Cabin with Air Conditioner AC Steel Track for Mini Excavator Clamshell Shovel](http://img6.grofrom.com/www.bailemachineco.com/226f3j00MiRhgnlzJupV/3-5-Ton-Yanmar-Kubota-Yanmar-Engine-Swing-Boom-Telescopic-Crawler-Open-Closed-Cabin-with-Air-Conditioner-AC-Steel-Track-for-Mini-Excavator-Clamshell-Shovel.webp)
Model | HX08 | HX10 | HX15 | HX17 |
Total Weight | 700 kg | 950 kg | 1280 kg | 1500 kg |
Rated Power | 8.6KW | 8.6 KW | 12KW | 20KW |
Engine | Koop192F | Koop 192FA | Changchai | Changchai |
Bucket Capacity | 0.02 m³ | 0.02 m³ | 0.03 m³ | 0.03 m³ |
Maximum digging distance | 2650 mm | 2850 mm | 3370 mm | 2400 mm |
Max. Digging Depth | 1200 mm | 1450 mm | 1600 mm | 1800 mm |
Max. Digging Height | 2470 mm | 2580 mm | 2850 mm | 2940 mm |
Gradeability | 30° | 30° | 30° | 30° |
Overall Width | 720 mm | 930 mm | 1100 mm | 1100 mm |
![3.5 Ton Yanmar Kubota Yanmar Engine Swing Boom Telescopic Crawler Open Closed Cabin with Air Conditioner AC Steel Track for Mini Excavator Clamshell Shovel](http://img6.grofrom.com/www.bailemachineco.com/226f3j00ZlRhrQiqqzuW/3-5-Ton-Yanmar-Kubota-Yanmar-Engine-Swing-Boom-Telescopic-Crawler-Open-Closed-Cabin-with-Air-Conditioner-AC-Steel-Track-for-Mini-Excavator-Clamshell-Shovel.webp)
Model | HX18T | HX20 | HX20T | HX20U |
Total Width | 1100 mm | 1060 mm | 1300 mm | 1200 mm |
Crawler width | 180 mm | 230 mm | 230 mm | 230 mm |
Engine | Kubota D1105/Laidong 385 | Kubota D1105 | Kubota D1105 | Laidong |
Bucket Capacity | 0.04 m³ | 0.06 m³ | 0.06 m³ | 0.06m³ |
Swing angle | 360° | 360° | 360° | 360° |
Max. Digging Depth | 2100 mm | 2050 mm | 2400 mm | 2240 mm |
Max. Digging Height | 2700 mm | 3365 mm | 3700 mm | 3550 mm |
Max. Digging Radius | 2990 mm | 3860 mm | 4040 mm | 3780 mm |
Max. Dumping Height | 1500 mm | 2385 mm | 2440 mm | 2450 mm |
![3.5 Ton Yanmar Kubota Yanmar Engine Swing Boom Telescopic Crawler Open Closed Cabin with Air Conditioner AC Steel Track for Mini Excavator Clamshell Shovel](http://img6.grofrom.com/www.bailemachineco.com/226f3j00sWUlruhPqzpV/3-5-Ton-Yanmar-Kubota-Yanmar-Engine-Swing-Boom-Telescopic-Crawler-Open-Closed-Cabin-with-Air-Conditioner-AC-Steel-Track-for-Mini-Excavator-Clamshell-Shovel.webp)
Model | HX22 | HX30 | HX35 | HX40 |
Total Width | 1200 mm | 1350 mm | 1500 mm | 1720 mm |
Crawler width | 230 mm | 230 mm | 230 mm | 300 mm |
Engine | Kubota/Laidong | Kubota/Xinchai/Changchai | Kubota/xinchai/Changchai | Kubota D1703 |
Bucket Capacity | 0.06 m³ | 0.1 m³ | 0.1 m³ | 0.12 m³ |
Swing angle | 360° | 360° | 360° | 360° |
Max. Digging Depth | 2240 mm | 2500 mm | 2500 mm | 3208 mm |
Max. Digging Height | 3550 mm | 3900 mm | 3900 mm | 4800 mm |
Max. Digging Radius | 4050 mm | 4040 mm | 4040 mm | 5359 mm |
Max. Dumping Height | 2450 mm | 2600 mm | 2600 mm | 3406 mm |
![3.5 Ton Yanmar Kubota Yanmar Engine Swing Boom Telescopic Crawler Open Closed Cabin with Air Conditioner AC Steel Track for Mini Excavator Clamshell Shovel](http://img6.grofrom.com/www.bailemachineco.com/226f3j00ZWGirhlBapzV/3-5-Ton-Yanmar-Kubota-Yanmar-Engine-Swing-Boom-Telescopic-Crawler-Open-Closed-Cabin-with-Air-Conditioner-AC-Steel-Track-for-Mini-Excavator-Clamshell-Shovel.webp)
HIXEN Mini Excavators are equipped with a backup hydraulic pipeline, with which a lot of tools could be attached to fulfill a wide range of works. That include but not limited as: Pavement Breaking, Trees Planting, Pipeline Installation, Trenches Digging, Tunnel Excavation, Building Foundations, Indoor Breaking, Farmland Clearing, Foundation Digging, Cable Landfill, etc.
![3.5 Ton Yanmar Kubota Yanmar Engine Swing Boom Telescopic Crawler Open Closed Cabin with Air Conditioner AC Steel Track for Mini Excavator Clamshell Shovel](http://img6.grofrom.com/www.bailemachineco.com/226f3j00siYWpMhJbzgV/3-5-Ton-Yanmar-Kubota-Yanmar-Engine-Swing-Boom-Telescopic-Crawler-Open-Closed-Cabin-with-Air-Conditioner-AC-Steel-Track-for-Mini-Excavator-Clamshell-Shovel.webp)
![3.5 Ton Yanmar Kubota Yanmar Engine Swing Boom Telescopic Crawler Open Closed Cabin with Air Conditioner AC Steel Track for Mini Excavator Clamshell Shovel](http://img6.grofrom.com/www.bailemachineco.com/226f3j00jhUlpNVHYguW/3-5-Ton-Yanmar-Kubota-Yanmar-Engine-Swing-Boom-Telescopic-Crawler-Open-Closed-Cabin-with-Air-Conditioner-AC-Steel-Track-for-Mini-Excavator-Clamshell-Shovel.webp)
![3.5 Ton Yanmar Kubota Yanmar Engine Swing Boom Telescopic Crawler Open Closed Cabin with Air Conditioner AC Steel Track for Mini Excavator Clamshell Shovel](http://img6.grofrom.com/www.bailemachineco.com/226f3j00nVYizQlGuruh/3-5-Ton-Yanmar-Kubota-Yanmar-Engine-Swing-Boom-Telescopic-Crawler-Open-Closed-Cabin-with-Air-Conditioner-AC-Steel-Track-for-Mini-Excavator-Clamshell-Shovel.webp)
Shandong HIXEN Machinery Co., Ltd, is a reputed manufacturer and exporter of construction machines with 13 years' experience. Located in the High-tech development zone of Shandong province, the company has developed into a comprehensive machinery group.
Since established, the company has been devoted to the scientific and technological innovation, precision manufacturing and all-around service. Now we have built a professional technical team which have large years' experience in machinery area; the modern production line including all the processing machines which ensure the precise manufacturing; the international standard management system which guarantee the whole process run fluently. With all the related certificates, we will always be strictly following the industry standard, fully control the production flow that the quality of every product will be better and better.
Besides domestic market, the products have also been supplied to numerous places all over the world which has earned large reputation and enjoyed great population.
We sincerely welcome all distributors, trading companies, local agents, and end users contact us and come to visit us.
![3.5 Ton Yanmar Kubota Yanmar Engine Swing Boom Telescopic Crawler Open Closed Cabin with Air Conditioner AC Steel Track for Mini Excavator Clamshell Shovel](http://img6.grofrom.com/www.bailemachineco.com/226f3j00nhUiruWqOzgV/3-5-Ton-Yanmar-Kubota-Yanmar-Engine-Swing-Boom-Telescopic-Crawler-Open-Closed-Cabin-with-Air-Conditioner-AC-Steel-Track-for-Mini-Excavator-Clamshell-Shovel.webp)
![3.5 Ton Yanmar Kubota Yanmar Engine Swing Boom Telescopic Crawler Open Closed Cabin with Air Conditioner AC Steel Track for Mini Excavator Clamshell Shovel](http://img6.grofrom.com/www.bailemachineco.com/226f3j00yVUhzlWKgrgi/3-5-Ton-Yanmar-Kubota-Yanmar-Engine-Swing-Boom-Telescopic-Crawler-Open-Closed-Cabin-with-Air-Conditioner-AC-Steel-Track-for-Mini-Excavator-Clamshell-Shovel.webp)
- Confirm ordering quantity so that we use wooden box or load into container.
- Make it clear how the quantity each container could load according to size of each model.
- Decide how to transport according to our trade terms.
- With the detailed address, deliver the goods to your destination port.
![3.5 Ton Yanmar Kubota Yanmar Engine Swing Boom Telescopic Crawler Open Closed Cabin with Air Conditioner AC Steel Track for Mini Excavator Clamshell Shovel](http://img6.grofrom.com/www.bailemachineco.com/226f3j00OifhrCWGOpgl/3-5-Ton-Yanmar-Kubota-Yanmar-Engine-Swing-Boom-Telescopic-Crawler-Open-Closed-Cabin-with-Air-Conditioner-AC-Steel-Track-for-Mini-Excavator-Clamshell-Shovel.webp)
![3.5 Ton Yanmar Kubota Yanmar Engine Swing Boom Telescopic Crawler Open Closed Cabin with Air Conditioner AC Steel Track for Mini Excavator Clamshell Shovel](http://img6.grofrom.com/www.bailemachineco.com/226f3j00OlYiznVJnrgh/3-5-Ton-Yanmar-Kubota-Yanmar-Engine-Swing-Boom-Telescopic-Crawler-Open-Closed-Cabin-with-Air-Conditioner-AC-Steel-Track-for-Mini-Excavator-Clamshell-Shovel.webp)
![3.5 Ton Yanmar Kubota Yanmar Engine Swing Boom Telescopic Crawler Open Closed Cabin with Air Conditioner AC Steel Track for Mini Excavator Clamshell Shovel](http://img6.grofrom.com/www.bailemachineco.com/226f3j00JhRVuTlPqrgi/3-5-Ton-Yanmar-Kubota-Yanmar-Engine-Swing-Boom-Telescopic-Crawler-Open-Closed-Cabin-with-Air-Conditioner-AC-Steel-Track-for-Mini-Excavator-Clamshell-Shovel.webp)
1. What kind of payment terms can be accepted?
We accept 30% initial deposit that we start the production, and 70% payment when the goods are ready before delivery through T/T. L/C or Trade Assurance on Alibaba could also be accepted. Further methods need to be negotiated.
2. What will be the international trading terms can you accept when we make the deal?
We work on FOB,CFR,CIF, DDU, DDP etc. We have the professional shipping forwarder to arrange all the shipping process, even the door to door delivery. Meanwhile, you can also handle the transportation yourself.
3. What is the delivery period?
Usually we can deliver the goods within 5 working days after receiving the deposit. If your ordering quantity is large, that need to be further negotiated. The shipping period depends on your destination port distance, which will be clear during your conversation with our commercial team.
4. What is the minimum ordering quantity?
The MOQ is 1 set. And we can help pack it inside the wooden box for LCL shipping. While, large quantity is always welcomed, since the shipping cost could be lower comparatively.
5. Could you make our brand LOGO or color customized on the products?
Yes, sure. We accept the OEM/ODM orders.
6.How long does it usually take for me to receive the mini diggers?
That depends on whether you want to do customization your mini diggers or not, and also depends on the speed of customs clearance and logistics, but we can guarantee to ship regular models within 5 working days, and some in stock ready for delivery.
7. How can you guarantee the quality of your mini diggers?
We have been in the mini digger industry for over 10 years, the technology is quite mature. Each product can only be delivered after our strict test and commission. Also, the satisfaction from end-users proved its quality.
8. How to operate a mini excavator?
When we deliver the mini excavators, the instruction manuals will be provided, with basic operation indicates, and repair and maintenance instructions. It will be quite easy to operate.
9. Which model micro diggers is the most popular one?
This is a great and tough question. The hot-selling models vary in different countries. For us, the 2-ton model is always very popular, but the 1-ton digger enjoyed a great market in recent years. Anyway, please do some investigation on your local market, we can also provide some suggestions according to your specific requirement.
10. What kind of attached tools could be equipped to the mini diggers?
Basically, almost all the tools used on hydraulic excavators could be used on our micro diggers. The most common ones such as Auger, Breaking Hammer, Log Grapple, Ripper, Rake, Thumb, Wide Bucket, Narrow Bucket, Fork, etc.
