Product Description
Main Features:
1. High flexibility and broad adaptability ;
2. Adaptable to different work requirements ;
3. Flexible rotation and precise focus ;
4. High rates of return.
| HWL80 (Xinchai gear pump) | ||
| Model | Unit | HWL80 |
Machine weight | kg | 7200 |
Bucket capacity | M3 | 0.28 |
| Engine | ||
| Model | xinchai4D | |
| Rated power/speed | kw/rpm | 48/2200 |
| Speed at maximum torque | Nm/rpm | 245/1350~1650 |
| Fuel tank volume | L | 130 |
| Hydraulic system | ||
Model (Hydraulic pump) | Imported gear pump | |
Specified discharge | ml/r | 25+27+4 |
Pilot pressure | Mpa | 4 |
Rated flow | L/min | 90 |
Hydraulic tank capacity | L | 110 |
Max.dumping height | mm | 4863 |
| Normal operating range and digging force | ||
| Maximum digging radius | mm | 6147 |
| Maximum excavation height | mm | 6647 |
| Maximum unloading height | mm | 4863 |
| Boom length | mm | 3450 |
| Bucket Digging Force | kn | 44 |
| Gradeability | 35 degrees | |
| Swing speed | rpm | 10.5 |
| Size | ||
| Shipping length | mm | 6000 |
| Transport height | mm | 2730 |
| Machine width | mm | 2020 |
| Tire diameter | mm | 850 |
| Wheelbase | mm | 2400 |
| Wheel track | mm | 1670 |
| Bulldozing plate height | mm | 382 |
| Bulldozing board width | mm | 2017 |
| Push plate lift height | mm | 360 |
| Height of push plate support | mm | 50 |
excavator cab interior configuration
comfort:
| The picture above is a detailed view of the interior of the HW-80 excavator cab, equipped with heating and cooling air conditioning; radio; LCD screen Space suspension seat; display reversing image, mor secure. |
| The detail in the lower right corner of the picture above is the security lock. After locking according to the prompt direction,the machine can not work, which increases the safety when it is not working. |
| The tires are semi-solid tires with large rubber originality and good shock absorption effect. Gives you an excellent experience even if you use it on rough roads. |
| Free toolbox; Machine filter, air filter, oil filter; Contact customer service for preferential rates,please click !!! Δ |
RODUCT UPGRADE
spacious and bright.
Fuel efficient!
hydraulic system can give full play to the power of the engine, and save fuel even under various complicated working conditions.
Long service life!
Wheeled Excavators is widely used in the drive of mining soil, mining machinery and excavation operations, as well as large-scale operations in the field of materials. Transportation equipment and other supporting facilities form a continuous operation line.
