Basic Info.
Model NO.
HY-10
Usage
Special Excavator, Marine Excavator, Mining Excavator, GM Excavator
Bucket
Tooth Bucket
Transmission
Hydraulic Transmission
Drive Type
Hydraulic Motor
Bucket Capacity
0.03
Size
Small-Scale
Certification
CE, ISO9001: 2000, EPA/Euro 5
Condition
New
Track Width
150mm
Working Weight
1000kg
Walking Speed
2.2km/H
Pump Type
Gear Pump
Working Pressure
14MPa
Maximum Digging Distance
2450mm
Transport Package
Wooden Packing
Specification
250*900*150cm
Trademark
HANYUE
Origin
China
Packaging & Delivery
Package Size
250.00cm * 900.00cm * 150.00cm
Package Gross Weight
1000.000kg
Product Description
| Total width | 720-780mm | Model | 0.8Ton Hydraulic Excavator |
| Total height | 1300mm | Gradeability | 30° |
| Total length | 2430mm | Ground specific pressure | 19Kpa |
| Minimum ground clearance | 80mm | Pump type | |
| Track ground length | 1140mm | Working pressure | 14MPa |
| Track width | 150mm | Maximum digging distance | 2450mm |
| Engine model | Briggs and Stratton EPA engine / Diersel engine | Digging depth | 1300mm |
| Rated power | 13.5HP | Digging height | 2350mm |
| Bucket capacity | 0.025m3 | Unloading height | 1600mm |
| Working weight | 800Kg | Minimum turning radius | 1100mm |
| Digging force | 7.5KN | Bulldozer blade maximum ground clearance | 120mm |
| Walking speed | 2.2Km/h | Dozer blade maximum support depth | 200mm |
1. Optional Brigg Stratton EPA gasoline engine / KOOP diesel engine, to meet environmental protection, cost control and other needs.
2. Designed with a back cover, it has a good-looking appearance and is anti-resonance. It will not be affected by refueling or replacing the filter element.
3. Strengthen the engineering rubber track, built-in steel core and steel wire, wear-resistant and durable.
4. The cylinder oil seal is of good quality, durable, good sealing performance and low failure rate.
5. The surface of the whole machine is spray-coated, not painted.
FAQ
1.Q:What is your payment term ? A:We accept T/T, Western Union, Paypal etc.
2.Q:Do you have CE certificate ? A:Yes, most of our products have the CE certificate
3.Q:What is your MOQ? A:1Sets.
4.Q:What is the product warranty period?
A:We have 12 months warranty.Provide after-sales service support andagricultural technical support.
5.Q: Which countries do you sell mini excavators to? A: United States, Australia, United States, Mexico, United Kingdom, Italy, Germany, France and Southeast Asia, etc.
6.Q:How to install the equipment after purchasing ? A:We will provide professional installation video to illustrate.Also provide manual.
