Product Description
Bucket Capacity | 0.09m3 | Engine | customize |
Excavator Width | 1550mm | Engine Power | 18.1kw/2200rpm |
Track Length | 2100mm | Turning Radius | 2035mm |
Track Width | 290mm | Max.Digging Height | 4600mm |
Crawler Material | Rubber / steel track | Max.Dumping Height | 3175mm |
Track Width | 300mm | Max.Digging Depth | 2880mm |
MAX.Digging Force | 26.5 KN | Max.Digging Radius | 4845mm |
Excavator Height | 2440mm | Max.Vertical Digging Depth | 2305mm |
OverallDimension(LxWxH) | 4485*1550*2440mm | Operating Weight | 3500kg |
Provide OEM and ODM services.
We are a trustworthy company Choose TOROS For Mini Excavator!!!
Warranty period: within one year after delivery / 2000 working hours, if there is any quality problem, we will provide you with accessories for free.
1. Optional Yanmar (EPA certified) / Changchai / Laidong engines, to meet environmental protection, cost control and other needs.
2. It adopts the first-line brand high-precision 8-way multi-way valve. The valve core has its own buffer function and is controlled by ECU computer, which makes the action more flexible.
3. 1.3 tons, 1.5 tons, 1.6 tons, 1.8 tons, 2 tons, 3 tons can be equipped with high precision pilot control system.
4. Adopting Japan NACHI / American ETON hydraulic motor, small size, light weight, high efficiency and long service life.
5. Use Shimadzu gear pump / DOOSAN load sensitive variable displacement piston pump for continuous operation for up to 8 hours.
6. The boom can swing from side to side with high flexibility to meet the needs of small space operations.
7. Optional with tail or no-tail to meet the construction needs under different conditions.
8. Strengthen the engineering rubber track, built-in steel core, wear-resistant and durable.
9. Made of German Continental brand tubing, made of natural rubber. The interior uses dense steel wire to increase the service life.
Bucket Capacity | 0.04m3 | Engine | diesel engine |
Excavator Width | 1110mm | Engine Power | 10.2kw/2500rpm |
Track Length | 1585mm | Turning Radius | 1430mm |
Track Width | 230mm | Max.Digging Height | 3540mm |
Crawler Material | Rubber / steel track | Max.Dumping Height | 2440mm |
Transport Length | 3570mm | Max.Digging Depth | 2310mm |
MAX.Digging Force | 14.8KN | Max.Digging Radius | 3840mm |
Excavator Height | 2250mm | Max.Vertical Digging Depth | 1910mm |
Overall Dimension( LxWxH) | 3570*990*2250mm | Operating Weight | 2000kg |
Bucket Capacity | 0.066m³ | Engine | YANMAR3TNV76 |
Chassis Width | 1500mm | Power | 12HP |
Track Length | 1860mm | Turning Radius | 1850mm |
Chassis Ground Clearance | 170mm | Max.Digging Height | 3880mm |
Gradeability | 30° | Max.Dumping Height | 2320mm |
Track Width | 250mm | Max.Digging Depth | 1200mm |
Shipping & Payment
For Transportation, We Have Three Methods: Sea, Air, And Land, And Support Multiple Payment And Multiple Transportation Methods. You Can Receive This Mini Excavator You Like At The Port, And Of Course You Can Also Receive The Mini Excavator At Your Doorstep.(The Cost Is Higher, Not Recommended),We Guarantee That We Will Not Charge Any Intermediate Fees And Extra Fees That Exceed The Shipping Cost,We Just Want You To Get This Favorite Mini Excavator Faster And More Preferentially! !
FAQ
Q:Can The Factory Support Mass Production? Can I Purchase A Customized Sample First?
A:Dear friends, TOROS company can support mass production. It can mass produce 200+mini excavator in one month, and can support customization (one piece is fine), but it cannot provide free prototypes. Please forgive me, my friend!
Q:Can It Be Transported To My Door? I Want To Get My Favorite Mini Excavator Soon?
A:Of Course, My Friend, But If Your Family Is Located Very Close To The Port, We Suggest That You Can Go Directly To The Port To Transport Your Goods, So You Can Save A Lot Of Money! If The Distance Is Long, You Can Find An Inland Transportation Company By Yourself, And We Can Communicate With Him; We Can Also Find An Agency For You, But The Toll Will Be Very High (Not Recommended) During Transportation,We Will Not Charge Any Intermediate Fees And Additional Service Fees Other Than Freight.We Just Want You To Get Your Favorite Mini Excavator Earlier.
Q:How Can I Guarantee After-Sales After I Buy It?
A:Dear friends,our machine has a one-year/1000H work warranty period. During this time, if there is any problem with the machine itself,we will repair it for you free of charge, but if it is man-made damage, we will Not responsible for the maintenance of the machine, please forgive me, my friend.
