Basic Info.
Product Description
| Specification | Value |
| Power | Conventional Power |
| Manufacturer | Domestic |
| Bucket Type | Backhoe |
| Weight (ton) | 7 |
| Operating Weight (kg) | 7280 |
| Bucket Capacity (m³) | 0.12-0.32 |
| Performance | |
| Swing Speed (rpm) | 11.5 |
| Travel Speed (km/h) | 4.4/2.4 |
| Gradeability (%) | 70% (35°) |
| Ground Pressure (Kpa) | 33 |
| Bucket Digging Force (kN) | 56 |
| Arm Digging Force (kN) | 38 |
| Power System | |
| Engine Model | Isuzu AU-4LE2X |
| Rated Power (kW/rpm) | 43/2200 |
| Maximum Torque (N.m) | 200/1600 |
| Displacement (L) | 2.179 |
| Number of Cylinders | 4 |
| Cooling Method | Water-cooled |
| Fluid Capacities | |
| Fuel Tank (L) | 150 |
| Hydraulic Tank (L) | 120 |
| Engine Oil Change (L) | 9.5 |
| Dimensions | |
| Overall Length (mm) | 6120 |
| Overall Width (mm) | 2220 |
| Overall Height (mm) | 2720 |
| Track Ground Length (mm) | 2195 |
| Track Total Length (mm) | 2820 |
| Track Width (mm) | 450 |
| Track Shoe Pitch (mm) | 1750 |
| Minimum Ground Clearance (mm) | 380 |
| Rear Swing Radius (mm) | 1800 |
| Number of Carrier Rollers (per side) | 1 |
| Number of Track Shoes (per side) | 39 |
| Number of Idlers (per side) | 5 |
| Working Range | |
| Maximum Digging Radius (mm) | 6240 |
| Maximum Digging Depth (mm) | 4020 |
| Maximum Digging Height (mm) | 7060 |
| Maximum Dumping Height (mm) | 5155 |
| Maximum Vertical Digging Depth (mm) | 3290 |
| Blade Lifting or Digging Depth (mm) | 350/360 |
1.How can we guarantee quality and does the machines are original?
Yes ,all the machines are original ,and our engineers will conduct quality inspection every time brfore shipment.
2. What can you buy from us?
Used Excavator,Mini excavators,Used crane,Used Grader,Used Loader,Used Bulldozer,Used Roller,Used dump trucks
3.What services can we provide?
we can have meeting on-line video call to check these machines details and performance,and we can provide all the details and to present the machines to you.if it necessary, you can visit our factory.
4. How can we make a deal done?
Inspecting the machine-->if satisfied-->paying 30% deposit-->booking vessel --pay the balance --loading-->getting the B/L.
5.How long will it deliver to your country?
The estimation days for deliver to your country is around 15 - 45 days
