Basic Info.
Product Description
Popular 21t Excavator Xe215cll with Long Boom
1, High-end configuration·Excellent performance
XE215CLL is suitable for earth and stone construction projects such as municipal construction, highway bridges, housing
construction, road engineering, farmland water conservancy construction, port construction and so on, it has features of good flexibility and maneuverability, low fuel consumption, high construction efficiency, large digging force, comfortable driving environment and wide range of application.
2, New generation·Environmental·Energy-saving·Large power engine
* New generation environmental engine is adopted in this machine, which has both excellent environmental performance and large power, matched with ow fuel consumption design, operating costs are significantly reduced, and fuel consumption is reduced by 10% or less compared to previous generation of machine.
* With independently developed intelligent study-type control system in XE215CLL series, it can be matched efficiently and
reasonably so that the resistance of hydraulic oil return system is greatly decreased, working efficiency reaches above 15% (compared with old model XE215CLL), which has the highest earthwork efficiency among similar models.
Model | Unit | XE215CLL | |
Operating weight | kg | 22350 | |
Standard bucket capacity | m³ | 0.5 (standard) | |
Engine | Engine Model | / | CC-6BG1TRP |
Rated power/speed | kw/rpm | 128.5/2100 | |
Max. torque/speed | N.m | 551/1600 | |
Displacement | L | 6.494 | |
Working range | A Max. digging height | mm | 13250 |
B Max. dumping height | mm | 10942 | |
C Max. digging depth | mm | 11690 | |
D 8inch horizonal digging depth | mm | --- | |
E Max. vertical wall digging depth | mm | 11200 | |
F Max. digging reach | mm | 15394 | |
G Min. swing radius | mm | 4835 |
