Product Description
Features: 1. Excavators with compact dimensions can easily drive through narrow passages and doors.
2. Retractable undercarriage and dozer blade allow the excavators to be configured for excellent working stability and optimum performance.
3. Powerful engine and perfectly matched hydraulics provide efficient, economical and reliable performance for the toughest of jobs.
4. Bucket hoses are well protected within the boom and the cylinder is mounted above the structure.
5. The operator area is spacious and laid out to provide comfort and ease of operation.
6. Excellent engine provides excellent power with minimal fuel use for more productivity per tank.
| SD10S MINI EXCAVATOR MAIN PARAMETERS | |
| Overall size | |
| Platform Ground Clearance | 370mm |
| Arm Length | 1050mm |
| Min Ground Clearance | 150mm |
| Bucket Width | 300mm |
| Machine parameters | |
| Weight | 760Kg |
| Bucket Capacity | 0.02m³ |
| Rated Power | 7.6KW |
| Rated Rotation Speed | 3000kwr/min |
| Max. Grade | 30° |
| Max. Ground Pressure | 18.9N/m² |
| Max Walking Speed | 1.8Km/h |
| Max. Traction | 9.2KN |
| Platform Rotation Speed | 9-12rpm |
| Working range | |
| Max. Digging Height | 2350mm |
| Max. Dumping Height | 1450mm |
| Max. Digging Depth | 1300mm |
| Max Digging Radius | 2280mm |
| Min. Radius of Gyration | 1100mm |
| Max. Ground Clearance of Bulldozer | 180mm |
| Max. Support Depth of Bulldozer | 200mm |
| Machine configure | |
| Model No: | SD10S |
| Engine Model | Koop192F |
| Main Pump | Gear Pump |
| Rotation/Walking Motor | China Famous Motor |
Factory introduction: Our company has more than just a rigorous working attitude! A more pleasant working environment. While the employees of shanding Machinery Company continue to serve customers, they are also very happy to have parties and dinners. Our team, like our factory, is very large and advocates the combination of work and rest.
Shipping & PaymentFor Transportation, We Have Three Methods: Sea, Air, And Land, And Support Multiple Payment And Multiple Transportation Methods. You Can Receive This Mini Excavator You Like At The Port, And Of Course You Can Also Receive The Mini Excavator At Your Doorstep. (The Cost Is Higher, Not Recommended), We Guarantee That We Will Not Charge Any Intermediate Fees And Extra Fees That Exceed The Shipping Cost, We Just Want You To Get This Favorite Mini Excavator Faster And More Preferentially!
1.How long is the mini excavator warranty time?
A: One year.
2.which certification of mini excavator do you have?
A:CE,ISO900 1,SGS,etc.expect these for different countries,other certificates required by customer is agreed.
3.Is it convenient to see visit your factory and how go there?
A:Welcome everyone to come to visit our factory,we are in Dezhou city,near with Jinan airport.Also high speed train arrive at our city.Make sure your trip date we will arrange it for you.
4.What are our advantages compared with Manufacturer/Factories?
A:Competitive Price-we work as the leading dealers of various leading China
construction machinery,and are treated with best dealership prices everyyear.From numerous comparison and feedbacks from clients,our price is more competitive than Manufacturer/Factories.
Quick Response-Our team is consisted of a group of diligent and enterprising people,working 24/7 to response client inquires and question all the time.Most problems can be solved within 12 hours.
5.How long will our price be valid?
A:We are a tender and friendly supplier,never greedy on windfall profit.Basically,our price remains stable through the year.We only adjust our price based on two situations:
(1) The rate of USD: RMB varies significantly according to the international currency exchange rates.
(2) Manufacturers/Factories adjusted the machine price,because of the increasing labor cost,and raw material cost.
