Basic Info.
Model NO.
mini excavator
Drive Type
Internal Combustion Drive
Bucket Capacity
0.1~0.5m³
Size
Small-Scale
Certification
CE, ISO9001: 2000
Operating Mode
Hydraulic Lever
Rated Power
8.6kw
Main Pump
Shimadu
Max Travel Speed
2.5km/H
Track Type
Rubber Track
Transport Package
Sea, Land and Air Transport
Specification
2770*925*1000mm
Trademark
Haichuan environmental protection
Origin
China
HS Code
8701901190
Production Capacity
2000 Sets / Month
Product Description
EXCAVATOR
This small excavator is the one with the most stable performance and the strongest digging power among the 1-ton small excavators;
Suitable for small projects in your own garden nursery.
| Machine parameters | Machine configure | ||
| Model | 12d | Engine Model | KOOP 192F |
| Operating Weight | 1000Kg | Main valve | TIANJI |
| Bucket Capacity | 0.028m³ | Main Pump | Shimadzu |
| Rated Power | 8.6 kw | Rotation Motor | SANYO |
| Max.Hydraulic System Pressure | 16mpa | Walking Motor | SANYO |
| Max. Grade ability | 30° | Dimensions | |
| Max. Ground Pressure | 18.9N/m² | Overall Length | 2770mm |
| Max Walking Speed | 2.1Km/h | Overall Width | 925mm |
| Max. Traction | 9.2KN | Overall Height | 1550mm/2100(Chair/Roof) |
| Platform Rotary Speed | 9-11r/min | Arm Length | 800mm |
| Working range | Boom Length | 1490mm | |
| Max. Digging Height | 2650mm | Track Length | 1210mm |
| Max Digging Depth | 1650mm | Track Width | 180mm |
| Max. Digging Radius | 2950mm | Ground Clearance | 240mm |
| Max Dumping Height | 1750mm | Platform Width | 920mm |
| Min. Radius of Gyration | 1150mm | Platform Ground Clearance | 420mm |
| Radius of Tail Gyration | 680mm | Bucket Width | 370mm |
| Max. Sinking Depth of Bulldozer | 230mm | As the technology is constantly updated, the technical specifications are subject to change without prior notice | |
| Max. Lifting Depth of Bulldozer | 210mm | ||
Advantages of the mini excavator: support multi-function operations, quick attachment of accessories, excavation, crushing, trench clearing, drilling, and bulldozing;
Warranty period: within one year/2000 working hours after delivery, if there is any quality problem, we will provide you with accessories for free.
The latest configuration announcement: Mini excavator can increase the cab and air conditioning! ! !
Provide customized services, your exclusive purchase, personalized purchase, you are different from others!
